Specs
- UPC 193308241395
- Steering Control Twin levers with adjustable front reference bar to modify forward ground speed.
- Front Caster Tires 9 x 4.50-5, smooth-tread, semipneumatic tires with sealed ball bearings.
- Drive Tires 21x7.00-10 Kenda K506
- Parking Brake Lever-actuated bar brake.
- Tractor Frame Welded, heavy-duty 1.5" x 3" tubular steel.
- Blade Spindles No maintenance, sealed and nongreasable spindles; 7.75" diameter cutter housing with 1.75" diameter splined blade driver 1.0"-diameter spindle shaft.
- Cup Holder No
- Electrical 12-volt battery with 15-amp alternator.
- Standard Features Engine Hour Meter
- Engine Brand Kawasaki
- Engine Model FS600V
- Engine Displacement 603
- Engine Series V-Twin
- Fuel System Carbureted
- Speed Infinitely variable speed selection 0–7.5 mph (12.1 kmph) forward, 0–4.0 mph (6.4 kmph) reverse
- Engine Spec _S36
- Engine Speed 3,600 rpm
- Air Filter Standard Engine Manufacturer's air filter
- Fuel Capacity 5-gallon (18.9-L), single fuel tank with single fill location.
- Drive Description Two Hydro Gear 10 cc pumps powering two Parker 12 cubic inch motors.
- Fuel Type Gas Carbureted
- PTO Engagement Warner 105 ft-lb clutch
- Drive System Hydro-Drive
- Drive Wheel Release Allows unit movement without engine running.
- Fuel Indicator Yes - Float Gauge
- Deck Lift Single point HOC
- Carb Compliant Yes
- Safety Package Operator Presence Controls (OPC) with safety interlock system indicators
- Deck Style Floating Deck
- Deck Style Description Full-floating UltraCut Series 3. Side discharge standard, with flexible discharge chute and option to bag or mulch.
- Width / Cutting Deck 32"
- Deck Construction 7-gauge top that is formed and continuously seam welded, 7-gauge side skirt
- Cutting Heights 1.0" (2.54 cm) to 4.5" (11.4 cm) in 0.25" (0.64 cm) increments
- Blade Tip Speed Approximately 18,500 fpm.
- Blades 2 Blades at 16.25" Length
- Width 44.9
- Height 47.3
- Length 58.103
- Curb Weight 702
