Specs
- Width 75.4 in. (191.5 cm)
- Height 71.8 in. (182.4 cm)
- Length 82.3 in. (209.0 cm)
- Curb Weight 1414
- Engine Brand N/A
- Engine Model N/A
- Engine Displacement N/A
- Speed Infinitely variable speed selection from 0–11.0 mph (18 kmph) forward, 0–6 mph (10 kmph) reverse.
- Fuel System N/A
- Engine Series N/A
- Engine Speed N/A
- Drive Electric drive
- Engine Spec N/A
- Fuel Capacity N/A
- Air Filter N/A
- Drive Description Two Exmark exclusive Dana planetary gearset electric motors.
- Fuel Type Battery
- PTO Engagement N/A
- Fuel Indicator Battery charger level indicator
- Drive Wheel Release Allows unit movement without electric power.
- Deck Lift Standard; foot-controlled deck lift changes cutting height and lifts the deck to maneuver around obstacles, or place in transport position.
- Carb Compliant N/A
- Safety Package Operator Presence Controls (OPC) and drive system interlock, with safety interlock system indicators.
- ROPS 2-post foldable ROPS standard with seat belt and latch.
- Deck Style Floating Deck
- Deck Style Description Full-floating Electric Series 4. Side discharge standard, with molded discharge chute and option to bag or mulch.
- Width / Cutting Deck 60"
- Deck Construction 7-gauge high strength alloy top that is formed and seam welded, with 7-gauge high strength alloy side skirt.
- Cutting Heights 1.0" (2.5 cm) to 5.0" (12.7 cm) in 0.25" (0.64 cm) increments adjustable from operator’s seat.
- Blade Tip Speed Approximately 17,500 fpm.
- Blades 3 Blades at 20.50" Length
- UPC 193308225487
- Onboard Intelligence Proprietary control system
- Steering Control Hydraulically dampened twin levers, adjust fore and aft. Adjustable to 2 height positions.
- Caster Forks Cast steel fork
- Front Caster Tires 13 x 6.5-6, smooth-tread, semi-pneumatic.
- Drive Tires 24x12-12, 4 ply Grass Master®
- Parking Brake Spring applied/electrically released dry parking brake.
- Tractor Frame Unibody, welded, heavy-duty 2" x 3" tubular steel.
- Blade Spindles No maintenance, electric deck motor; 7.75"-diameter motor housing with 25mm (.98) diameter spindle shaft.
- Electrical 60-volt 23.4kWh HyperCell battery system.
- Standard Features USB plug-in, hour meter, and cup holder
- Seat Deluxe, two-tone, bolstered suspension seat with Elastomeric Vibration Control material. Mounted on innovative Seat Isolation System that provides operator isolation in all three planes of motion as well as fore-aft slide and seat flip-up.
